| Part No. | STGW80H65DFB-4 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | Trench gate field-stop IGBT, HB series 650 V, 80 A high speed |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 10 pcs | 100 pcs | 1000 pcs | 10000 pcs | |
|---|---|---|---|---|---|
| $6.46 | $5.832 | $5.26 | $5.146 | ||
Specifications
Data sheet
| Voltage - Collector Emitter Breakdown (Max): | 650V |
|---|---|
| Vce(on) (Max) @ Vge, Ic: | 2V @ 15V, 80A |
| Test Condition: | 400V, 80A, 10 Ohm, 15V |
| Td (on/off) @ 25°C: | 84ns/280ns |
| Switching Energy: | 2.1mJ (on), 1.5mJ (off) |
| Supplier Device Package: | TO-247-4L |
| Series: | - |
| Reverse Recovery Time (trr): | 85ns |
| Power - Max: | 469W |
| Packaging: | Tube |
| Package / Case: | TO-247-4 |
| Operating Temperature: | -55°C ~ 175°C (TJ) |
| Mounting Type: | Through Hole |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Manufacturer Standard Lead Time: | 42 Weeks |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Input Type: | Standard |
| IGBT Type: | Trench Field Stop |
| Gate Charge: | 414nC |
| Detailed Description: | IGBT Trench Field Stop 650V 120A 469W Through Hole TO-247-4L |
| Current - Collector Pulsed (Icm): | 240A |
| Current - Collector (Ic) (Max): | 120A |
