VN750
STMicroelectronics
Images are for reference only.
See Product Specifications for product details.
Buy VN750 with confidence from CJJhk.com, 1 Year Warranty
See Product Specifications for product details.
Buy VN750 with confidence from CJJhk.com, 1 Year Warranty
Request a Quote
| Part No. | VN750 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IC DRIVER HI SIDE 6A PENTAWATT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | ||||
|---|---|---|---|---|---|
| $1.378 | |||||
Specifications
Data sheet
| Voltage - Supply (Vcc/Vdd): | Not Required |
|---|---|
| Voltage - Load: | 5.5 V ~ 36 V |
| Switch Type: | General Purpose |
| Supplier Device Package: | 5-PENTAWATT |
| Series: | VIPower™ |
| Rds On (Typ): | 60 mOhm (Max) |
| Ratio - Input:Output: | 1:1 |
| Packaging: | Tube |
| Package / Case: | Pentawatt-5 (Vertical, Bent and Staggered Leads) |
| Output Type: | N-Channel |
| Output Configuration: | High Side |
| Other Names: | 497-2707-5 |
| Operating Temperature: | -40°C ~ 150°C (TJ) |
| Number of Outputs: | 1 |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Interface: | On/Off |
| Input Type: | Non-Inverting |
| Features: | Auto Restart, Status Flag |
| Fault Protection: | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
| Current - Output (Max): | 6A |
| Base Part Number: | VN750 |
| Email: | info@cjjhk.com |
Introduce
We can supply VN750, use the request quote form to request VN750 pirce and lead time.CJJ a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number VN750.The price and lead time for VN750 depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# VN750.We look forward to working with you to establish long-term relations of cooperation
