U6820BM-MFPG3Y
Images are for reference only.
See Product Specifications for product details.
Buy U6820BM-MFPG3Y with confidence from CJJhk.com, 1 Year Warranty
See Product Specifications for product details.
Buy U6820BM-MFPG3Y with confidence from CJJhk.com, 1 Year Warranty
Request a Quote
| Part No. | U6820BM-MFPG3Y |
|---|---|
| Manufacturer | Atmel |
| Description | SIPO Based Peripheral Driver, 8 Driver, BCDMOS, PDSO16 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a Quote | ||||
Specifications
Data sheet
| Voltage - Supply: | 4.5 V ~ 5.5 V |
|---|---|
| Voltage - Load: | 6 V ~ 18 V |
| Technology: | BCDMOS |
| Supplier Device Package: | 16-SO |
| Series: | - |
| Rds On (Typ): | 4 Ohm LS, 6.25 Ohm HS |
| Packaging: | Cut Tape (CT) |
| Package / Case: | 16-SOIC (0.154", 3.90mm Width) |
| Output Configuration: | Half Bridge (4) |
| Other Names: | U6820BM-MFPG3YCT U6820BMMFPG3Y |
| Operating Temperature: | -40°C ~ 150°C (TJ) |
| Mounting Type: | Surface Mount |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Load Type: | Inductive |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Interface: | SPI |
| Features: | Auto Restart, Status Flag |
| Fault Protection: | Current Limiting, ESD, Short Circuit, Over Temperature, Over Voltage, UVLO |
| Detailed Description: | Half Bridge (4) Driver General Purpose BCDMOS 16-SO |
| Current - Peak Output: | 50mA |
| Current - Output / Channel: | - |
| Base Part Number: | U6820B |
| Applications: | General Purpose |
| Email: | info@cjjhk.com |
Introduce
We can supply U6820BM-MFPG3Y, use the request quote form to request U6820BM-MFPG3Y pirce and lead time.CJJ a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number U6820BM-MFPG3Y.The price and lead time for U6820BM-MFPG3Y depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# U6820BM-MFPG3Y.We look forward to working with you to establish long-term relations of cooperation
