LB1863M-TLM-H
onsemi
Images are for reference only.
See Product Specifications for product details.
Buy LB1863M-TLM-H with confidence from CJJhk.com, 1 Year Warranty
See Product Specifications for product details.
Buy LB1863M-TLM-H with confidence from CJJhk.com, 1 Year Warranty
Request a Quote
| Part No. | LB1863M-TLM-H |
|---|---|
| Manufacturer | onsemi |
| Description | LB1863M-TLM-H Motor Driver; ; 65 V 1.5A; 14-Pin SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 10 pcs | 100 pcs | 1000 pcs | 10000 pcs | |
|---|---|---|---|---|---|
| $0.975 | $0.88 | $0.794 | $0.776 | ||
Specifications
Data sheet
| Voltage - Supply: | 6.4 V ~ 7 V |
|---|---|
| Voltage - Load: | 24V |
| Technology: | Bipolar |
| Supplier Device Package: | 14-SOIC / 14MFPS |
| Series: | - |
| Rds On (Typ): | - |
| Packaging: | Tape & Reel (TR) |
| Package / Case: | 14-LSOP (0.173", 4.40mm Width) |
| Output Configuration: | Half Bridge (2) |
| Operating Temperature: | -30°C ~ 80°C (TA) |
| Mounting Type: | Surface Mount |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Load Type: | Inductive |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Interface: | Logic |
| Features: | - |
| Fault Protection: | Over Temperature |
| Detailed Description: | Half Bridge (2) Driver DC Motors, General Purpose Bipolar 14-SOIC / 14MFPS |
| Current - Peak Output: | - |
| Current - Output / Channel: | 1.5A |
| Base Part Number: | LB1863 |
| Applications: | DC Motors, General Purpose |
| Email: | info@cjjhk.com |
Introduce
We can supply LB1863M-TLM-H, use the request quote form to request LB1863M-TLM-H pirce and lead time.CJJ a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LB1863M-TLM-H.The price and lead time for LB1863M-TLM-H depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# LB1863M-TLM-H.We look forward to working with you to establish long-term relations of cooperation
