| Part No. | KDE0504PFV1.11.MS.AF.GN |
|---|---|
| Manufacturer | Sunon |
| Description | FAN AXIAL 40X10MM VAPO 5VDC WIRE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a Quote | ||||
Specifications
Data sheet
| Width: | 10.00mm |
|---|---|
| Weight: | 0.037 lb (16.78g) |
| Voltage Range: | 4 ~ 6VDC |
| Voltage - Rated: | 5VDC |
| Termination: | 3 Wire Leads |
| Static Pressure: | 0.190 in H2O (47.3 Pa) |
| Size / Dimension: | Square - 40mm L x 40mm H |
| Series: | MagLev® KDE |
| RPM: | 7000 RPM |
| Power (Watts): | 1.20W |
| Other Names: | 259-1341 E0540PFU14AFVRG KDE0504PFV1 11.MS.AF.GN |
| Operating Temperature: | 14 ~ 158°F (-10 ~ 70°C) |
| Noise: | 32.0 dB(A) |
| Material - Frame: | Polybutylene Terephthalate (PBT) |
| Material - Blade: | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp.: | - |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Ingress Protection: | - |
| Features: | Speed Sensor (Tach) |
| Fan Type: | Tubeaxial |
| Current Rating: | 0.240A |
| Bearing Type: | Vapo-Bearing™ |
| Approvals: | CE, CUR, TUV, UL |
| Air Flow: | 8.0 CFM (0.224m³/min) |
