AS13AW
NKK Switches
Images are for reference only.
See Product Specifications for product details.
Buy AS13AW with confidence from CJJhk.com, 1 Year Warranty
See Product Specifications for product details.
Buy AS13AW with confidence from CJJhk.com, 1 Year Warranty
Request a Quote
| Part No. | AS13AW |
|---|---|
| Manufacturer | NKK Switches |
| Description | SWITCH SLIDE SPDT 0.4VA 28V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.13 | $3.956 | $3.784 | $3.354 | ||
| 100 pcs | 300 pcs | 500 pcs | 1000 pcs | ||
| $3.268 | $3.225 | $2.666 | $2.494 | ||
Specifications
Data sheet
| Voltage Rating - DC: | 28V |
|---|---|
| Voltage Rating - AC: | 28V |
| Termination Style: | Wire Wrap |
| Switch Travel: | 2.50mm |
| Switch Function: | On-Off-On |
| Series: | AS |
| Packaging: | Tray |
| Other Names: | 360-3409 AS13AW-ND |
| Operating Temperature: | -30°C ~ 85°C |
| Operating Force: | 260gf |
| Mounting Type: | Through Hole |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Mechanical Life: | 50,000 Cycles |
| Manufacturer Standard Lead Time: | 5 Weeks |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Features: | Epoxy Sealed Terminals |
| Electrical Life: | 50,000 Cycles |
| Detailed Description: | Slide Switch SPDT Through Hole |
| Current Rating: | 0.4VA (AC/DC) |
| Contact Timing: | Non-Shorting (BBM) |
| Contact Material: | Phosphor Bronze |
| Contact Finish: | Gold |
| Circuit: | SPDT |
| Actuator Type: | Standard |
| Actuator Material: | Polyamide (PA), Nylon, Glass Filled |
| Actuator Length: | 2.50mm |
| Email: | info@cjjhk.com |
Introduce
We can supply AS13AW, use the request quote form to request AS13AW pirce and lead time.CJJ a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AS13AW.The price and lead time for AS13AW depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# AS13AW.We look forward to working with you to establish long-term relations of cooperation
