1-745494-7
Agastat Relays / TE Connectivity
Images are for reference only.
See Product Specifications for product details.
Buy 1-745494-7 with confidence from CJJhk.com, 1 Year Warranty
See Product Specifications for product details.
Buy 1-745494-7 with confidence from CJJhk.com, 1 Year Warranty
Request a Quote
| Part No. | 1-745494-7 |
|---|---|
| Manufacturer | Agastat Relays / TE Connectivity |
| Description | CONN D-SUB PLUG 15POS STR IDC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $8.15 | $7.798 | $7.089 | $6.734 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $6.557 | $5.848 | $5.494 | $4.856 | ||
Specifications
Data sheet
| Wire Gauge: | 26-30 AWG |
|---|---|
| Voltage Rating: | 250V |
| Termination: | IDC, Discrete Wire |
| Shell Size, Connector Layout: | 2 (DA, A) |
| Shell Material, Finish: | Steel, Tin Plated |
| Series: | AMPLIMITE HDE-20 |
| Packaging: | Bulk |
| Other Names: | 17454947 A31967 |
| Operating Temperature: | -55°C ~ 105°C |
| Number of Rows: | 2 |
| Number of Positions: | 15 |
| Mounting Type: | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Material Flammability Rating: | UL94 V-0 |
| Manufacturer Standard Lead Time: | 19 Weeks |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Ingress Protection: | - |
| Housing Material: | Thermoplastic, Glass Filled |
| Flange Feature: | Housing/Shell (Unthreaded) |
| Features: | Grounding Indents |
| Detailed Description: | 15 Position D-Sub Plug, Male Pins Connector |
| Current Rating: | Varies by Wire Gauge |
| Contact Type: | Signal |
| Contact Material: | Phosphor Bronze |
| Contact Form: | - |
| Contact Finish Thickness: | 30.0µin (0.76µm) |
| Contact Finish: | Gold |
| Connector Type: | Plug, Male Pins |
| Connector Style: | D-Sub |
| Color: | Black |
| Backset Spacing: | - |
| Email: | info@cjjhk.com |
Introduce
We can supply 1-745494-7, use the request quote form to request 1-745494-7 pirce and lead time.CJJ a professional electronic components distributor. With 3+ Million line items of available electronic components can ship in short lead-time, over 250 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 1-745494-7.The price and lead time for 1-745494-7 depending on the quantity required, availability and warehouse location.Contact us today and our sales representative will provide you price and delivery on Part# 1-745494-7.We look forward to working with you to establish long-term relations of cooperation
