0ZCC0300FF2B
Bel
Images are for reference only.
See Product Specifications for product details.
Buy 0ZCC0300FF2B with confidence from CJJhk.com, 1 Year Warranty
See Product Specifications for product details.
Buy 0ZCC0300FF2B with confidence from CJJhk.com, 1 Year Warranty
Request a Quote
| Part No. | 0ZCC0300FF2B |
|---|---|
| Manufacturer | Bel |
| Description | PTC RESET FUSE 6V 3A 1812 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a Quote | ||||
Specifications
Data sheet
| Voltage - Max: | 6V |
|---|---|
| Type: | Polymeric |
| Time to Trip: | 4s |
| Thickness (Max): | 0.061" (1.55mm) |
| Size / Dimension: | 0.179" L x 0.128" W (4.55mm x 3.24mm) |
| Series: | 0ZCC |
| Resistance - Post Trip (R1) (Max): | 40 mOhms |
| Resistance - Initial (Ri) (Min): | 12 mOhms |
| Ratings: | - |
| Packaging: | Cut Tape (CT) |
| Package / Case: | 1812 (4532 Metric), Concave |
| Other Names: | 507-1513-1 |
| Operating Temperature: | -40°C ~ 85°C |
| Mounting Type: | Surface Mount |
| Moisture Sensitivity Level (MSL): | 2A (4 Weeks) |
| Lead Spacing: | - |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Height - Seated (Max): | - |
| Detailed Description: | Polymeric PTC Resettable Fuse 6V 3A Ih Surface Mount 1812 (4532 Metric), Concave |
| Current - Trip (It): | 5A |
| Current - Max: | 100A |
| Current - Hold (Ih) (Max): | 3A |
| Approvals: | cURus, TUV |
| Email: | info@cjjhk.com |
